Due 11:59:59AM January 14^th

For every student the university stores a wealth of information. Much of this data pertains to the student’s grade point average, (GPA). A GPA is computed by dividing the quality credits achieved by the credit hours attempted. Quality credits are earned for passing grades in courses. The quality credits earned in a course are obtained by multiplying the corresponding letter grade quality credits by the credit hours for the course. (See the table below for the letter grade quality credits.) Quality Points A  A- B+ B  B- C+ C  C- D+ D  D- F  4.0 3.7 3.3 3.0 2.7 2.3 2.0 1.7 1.3 1.0 0.7 0.0

A student has several GPAs: overall GPA, term GPA and major GPA. The overall GPA is the total quality credits achieved in all courses divided by the total credit hours attempted. A term or semester GPA is simply the quality credits earned during a particular term divided by the credit hours attempted during the term. A student’s major GPA is the sum of all the quality credits earned for courses taken in a student’s department divided by the total major departmental hours attempted. (Note: some schools and departments define major GPA differently. Courses passed with a grade of ’P’ do not affect a GPA, i.e. the hours are not counted in the hours attempted. )

The program you create for this assignment will compute students’ overall GPAs and major GPAs for all the courses each student has attempted plus statistics and produce bar chart GPA output..

Downloading Sample Input/Output Files

To download a file, right-click on the link. Select "Save Target As..." or "Save Link As...", choose your BlueJ project directory, and save it.

Student Data
Student Data Field Name	Field Contents
idNumber	character string
name	character string
address	character string
state	character string
zip	positive integer
major	character string
minor	character string
rank	positive integer
gpa	real value
altGPA	real value
qualCred	real value
hrsAtt	real value

The program must be designed to allow it to easily work with any input filenames without requiring the code of the class to be changed. This implies that I/O filenames must not be "hard wired" into the solution class code without the possibility of being changed. To satisfy this requirement command line parameters should be utilized. The order of the command line file name parameters should be student filename, courses filename, output filename. It is certainly acceptable for testing purposes to "hard wire" I/O file names in the testing code. There are two input files for this program: a student data file and a corresponding courses data file.

The "students.txt" student data file will store the student information. The format of the student file will now be described. The first line of the student input file is a label line that must be ignored. The second line specifies twelve data fields, separated by one tab character. The order of the data fields on the line and the type of value in the field are given in the "Student Data" table at the right. The last three fields are the alternate (major) GPA, the overall quality credits earned and the overall hours attempted. Note that the contents of the last four fields may not be up-to-date, (i.e. they should be assumed to be incorrect). Following the second line will be other lines of data for other students.
Sample input/output files are linked above. A sample student.txt input file is shown below:

// ID    	Name		Address			St	Zip  	Majr	Minr	Rk	QCA   	AltQCA	Crd	Hrs
135792468	Wayne,John Duke	101 Hollywood Way	CA	40815	CS	MATH	10	3.2667	4.0000	49	15
436587901	Mix, Tom	828 Dallas Ave	TX	52848	CS	MATH	20	3.1245	3.0000	54.0000	30.00
147036925	Brennan, Walter	939 Brownsville Ave	TX	71392	CS	MATH	30	3.2831	2.5200	54	30

Note that due to web browser window width limitations, (not file line size), the lines of the input file may wrap onto multiple lines.

Courses Data
Courses Data Field Name	Field Contents
idNumber	character string
index	positive integer
department	character string
courseNum	positive integer
term	character string
year	positive integer
creditHours	decimal place
grade	character string

The contents of the courses data file "courses.txt" file will now be explained. The first line is a label line that must be skipped. Each course record, starting on line 2 of the courses file, specifies 9 data fields, separated by one tab character. The order of the data fields on a line and the type of value in the field are given in the "Courses Data" table at the right. The term field abbreviations are as follows: FS - fall semester, SS - Spring Semester, U1 - first summer term, and U2 - second summer term. The grade field codes are given above in the letter grade quality credits table. Note: a generic Vector or generic ArrayList must be used to store all of the student record data.

A sample coursess.txt input file is shown below:

// ID Indx Dept Crse Tm Year Cred Grd Title 135792468 9345 CS 1044 FS 1999 3.00 A Intro Prog in C 135792468 5231 CS 1205 FS 1999 1.00 A Oper Sys Tools I 135792468 1350 CS 1206 SS 2000 2.00 B+ Oper Sys Tools II 135792468 9268 CS 1104 FS 1999 3.00 A Intro to CS 135792468 1365 CS 1704 SS 2000 3.00 B Intro Data Struct/SE 135792468 6075 ENGL 1105 FS 1999 3.00 C Fresh English 135792468 2080 ENGL 1106 SS 2000 3.00 B+ Fresh English 135792468 7410 MATH 1114 FS 1999 2.00 C+ Elem Lin Alg 135792468 7430 MATH 1205 FS 1999 3.00 B+ Calculus 135792468 3470 MATH 1206 SS 2000 3.00 B Calculus 135792468 3510 MATH 1224 SS 2000 2.00 B- Vector Geometry 135792468 8082 PHYS 2074 SS 2000 3.00 A- Hilights of Physics 436587901 0282 COMM 2054 U2 2001 3.00 C Intrp Film 436587901 9345 CS 1044 FS 1999 3.00 B+ Intro Prog in C 436587901 5231 CS 1205 FS 1999 1.00 B- Oper Sys Tools I 436587901 1350 CS 1206 SS 2000 2.00 P Oper Sys Tools II 436587901 9268 CS 1104 FS 1999 3.00 B+ Intro to CS 436587901 1365 CS 1704 SS 2000 3.00 B Intro Data Struct/SE 436587901 9267 CS 2704 FS 2000 3.00 C+ Obj Orient Prog 436587901 9260 CS 2504 FS 2000 3.00 F Intro Comp Org 436587901 2261 CS 2604 SS 2001 3.00 B Data Structures 436587901 6075 ENGL 1105 FS 1999 3.00 A Fresh English 436587901 2080 ENGL 1106 SS 2000 3.00 C- Fresh English 436587901 2181 ENGL 2344 SS 2001 3.00 A Sci Fic & Fan 436587901 0246 ENT 2004 U2 2001 3.00 B Insects Hum Soc 436587901 2184 HST 1504 SS 2001 3.00 F Hum, Sci & Tech 436587901 7410 MATH 1114 FS 1999 2.00 C Elem Lin Alg 436587901 7430 MATH 1205 FS 1999 3.00 A- Calculus 436587901 3470 MATH 1206 SS 2000 3.00 C+ Calculus 436587901 3510 MATH 1224 SS 2000 2.00 D Vector Geometry 436587901 7264 MATH 2224 FS 2000 3.00 C- Mult Var Calc 436587901 9276 MATH 2534 FS 2000 3.00 A Discrete Math 436587901 4471 MATH 2214 SS 2001 3.00 C- Diff Eqns 436587901 8082 PHYS 2074 SS 2000 3.00 D Hilights of Physics 436587901 8140 PHYS 2305 FS 2000 4.00 C Found Phys I 436587901 7142 PHYS 2306 SS 2001 4.00 A Found Phys I 436587901 0138 PSYC 2004 U1 2001 3.00 B- Intro Psych 436587901 0126 SOC 1004 U1 2001 3.00 C- Intro Soc 147036925 3429 CHEM 1035 FS 2001 3.00 A- General Chemistry 147036925 3432 CHEM 1045 FS 2001 3.00 C General Chemistry La 147036925 0282 COMM 2054 U2 2001 3.00 B- Intro Film 147036925 9345 CS 1044 FS 1999 3.00 A Intro Prog in C 147036925 5231 CS 1205 FS 1999 1.00 C+ Oper Sys Tools I 147036925 1350 CS 1206 SS 2000 2.00 B+ Oper Sys Tools II 147036925 9268 CS 1104 FS 1999 3.00 A- Intro to CS 147036925 1365 CS 1704 SS 2000 3.00 C+ Intro Data Struct/SE 147036925 9267 CS 2704 FS 2000 3.00 C+ Obj Orient Prog 147036925 9260 CS 2504 FS 2000 3.00 B Intro Comp Org 147036925 2261 CS 2604 SS 2001 3.00 C Data Structures 147036925 6420 CS 3204 FS 2001 3.00 C+ Oper Sys 147036925 6532 CS 3414 FS 2001 3.00 A Numerical Methods 147036925 6536 CS 3604 FS 2001 3.00 B- Prof Computing 147036925 6075 ENGL 1105 FS 1999 3.00 B- Fresh English 147036925 2080 ENGL 1106 SS 2000 3.00 B- Fresh English 147036925 2181 ENGL 2344 SS 2001 3.00 A Sci Fic & Fan 147036925 0246 ENT 2004 U2 2001 3.00 P Insects Hum Soc 147036925 2184 HST 1504 SS 2001 3.00 C Hum, Sci & Tech 147036925 7410 MATH 1114 FS 1999 2.00 A Elem Lin Alg 147036925 7430 MATH 1205 FS 1999 3.00 P Calculus 147036925 3470 MATH 1206 SS 2000 3.00 C+ Calculus 147036925 3510 MATH 1224 SS 2000 2.00 B- Vector Geometry 147036925 7264 MATH 2224 FS 2000 3.00 C- Mult Var Calc 147036925 9276 MATH 2534 FS 2000 3.00 P Discrete Math 147036925 4471 MATH 2214 SS 2001 3.00 C- Diff Eqns 147036925 6471 MATH 3134 FS 2001 3.00 B- App Comb & Graph The 147036925 8082 PHYS 2074 SS 2000 3.00 A Hilights of Physics 147036925 8140 PHYS 2305 FS 2000 4.00 D+ Found Phys I 147036925 7142 PHYS 2306 SS 2001 4.00 B+ Found Phys I 147036925 0138 PSYC 2004 U1 2001 3.00 C+ Intro Psych 147036925 0126 SOC 1004 U1 2001 3.00 B Intro Soc

It may also NOT be assumed that the course records in the file will be in any particular order. You may assume that the student and course data is valid and does not need to be checked for errors. Your program must be written so that it will detect when it’s out of input and terminate correctly.

The first line of your output must display the column labels shown below. The second and following lines will contain student data, ordered by name, aligned under the appropriate headers, echoed from the input file, and showing the results of the GPA calculations. Note that the GPA calculations must be based upon all of the course file records. The line following the GPA computations must be blank.

The next section of the output, will give a horizontal bar chart of each student’s GPA in corresponding order by name, but labeled by their ID. The beginning of the chart must have the columns labels exactly as shown. The number of following lines of the output file, (the GPA bar chart lines), will depend upon the number of student input records. Each line, one per student, will contain the ID aligned under the label, immediately followed by a colon. Beginning in column eleven on each line will be a number of asterisks representing the GPA bar chart value for that term. Forty columns will be used for the bar chart line representation of each GPA. To determine how many asterisks for a GPA should be output, a mapping of the numerical GPA value to the maximum column length must be performed. The equation for this mapping is: (GPA/MaxGPA) * MaxColumnLength, for this particular bar chart the formula becomes: (GPA/4.0) * 40. The mapping should be rounded to the nearest integer value for an exact number of asterisks to be output.

An instructor needs to determine certain statistics upon all of the students' GPAs. Along with a mean, (average of the GPAs, represented by the Greek letter μ), another important statistic that needs to be computed is the standard deviation, (represented by the Greek letter σ). The standard deviation is a measure of dispersal of values in a population about the mean. (A value in this case is a student's GPA and the population is the data set of all of the students' GPAs.) For another example, IQ scores typically have a mean of 100 and a standard deviation of 15. If one were to chart IQ scores for a group of normal student the graph at the right would most likely be produced.

The most important result in the field of statistics, the Central Limit Theorem, explains why most populations tend to fall into this type of distribution, called a normal distribution and how population values are dispersed. Instructors tend to use the standard deviation to determine letter grades , among other things. One of the formulas that can be used to compute the standard deviation for a population of student GPAs is:

Your program must, by default, write output data to a file named gpa.txt The sample output file shown below corresponds to the input data given above:

ID Number Name Major Minor Rank GPA AltGPA QCredits Hours Att. 147036925 Brennan, Walter CS MATH 30 2.7631 2.9267 232.1000 84.00 436587901 Mix, Tom CS MATH 20 2.4370 2.4947 177.9000 73.00 135792468 Wayne,John Duke CS MATH 10 3.2097 3.6333 99.5000 31.00 Student GPAs: ID Number ........1.0.......2.0.......3.0.......4.0 147036925:**************************** 436587901:************************ 135792468:******************************** Average GPA: 2.8033 Standard Deviation: 0.3167

You are NOT required to use this exact horizontal spacing. Your output must satisfy the output requirements of the previous program as they logically apply. In addition, the output for this program must satisfy the following constraints:

• You must use variables of type double for the mean and the standard deviation.
• All decimal values must be printed to show the same number of decimal places, 4 or 2, as in this sample.
• You must use the exact specified header and column labels given above.
• You must arrange your output in neatly aligned columns, with the identifying labels shown in the example.
• You must use the same ordering of the columns as shown here.
• You must print a newline at the end of each line, including the last line.

Student Class

You must provide a class called Student to model a student and their grade information.

• Your Student class must contain a default constructor.
• Your Student class must provide a method with the following signature:

  public boolean inputStuData( String inStudent )

  {
  	// ...
  }


  The Student.inputStuData( ) method must correctly read all of the student data into the corresponding fields from the provided message String.
• Your Student class must also provide a method with the following signature:

  public boolean inputCoursesData( String inCourse )
  {
  	// ...
  }


  The Student.inputCoursesData() method must simply use the Course class inputCourseData method, (see below) to create a corresponding Course object, storing the new object in the Student Vector or ArrayList.
• Your Student class must provide a method with the following signature:

  public boolean outputStuData( PrintWriter outStream )
  {
  	// ...
  }


  The Student.outputStuData( ) method must correctly write the student data into the outStream using the output format described previously.
• Your Student class must also provide an accessor method for each Student field. An accessor method is simply a method that returns the current value of the field. The first Student accessor method would have the following signature:

  public String idNumber()
  {
  	// ...
  }


  Note that the accessor methods affected by the input of student course data may need to invoke helper methods to compute the current value of the field.

• Your Student class must also provide a method to return the number of courses for a student. The Student numCourses method must have the following signature:

  public int numCourses()
  {
  	// ...
  }

• Your Student class must also provide an toString method to convert a Student object to a String object for display. The student id number must occur first in the returned String.

• Your Student class must also provide an equals method for comparing two Student objects.

Course Class

You must also provide a class called Course to model a single course that a student has taken.

• Your Course class must contain a default constructor.
• Your Course class must provide a method with the following signature:

  public boolean inputCourseData( String inCourse )
  {
  	// ...
  }


  The Course.inputCourseData() method must correctly read all of the student course data into the corresponding fields from the from the provided string inCourse.

• Your Course class must also provide an accessor method for each Course field. The second Course accessor method would have the following signature:

  public int index()
  {
  	// ...
  }

• Your Course class must also provide a quality credits method that returns the number of quality credits earned for the Course. The qualCredits method would have the following signature:

  public double qualCredits()
  {
  	// ...
  }

• Your Course class must also provide an toString method to convert a Course object to a String object for display. The student id number must occur first in the returned String.

• Your Course class must also provide an equals method for comparing two Course objects.

Advisees Class

You must also provide a class called Advisees to model a group of students.

• Your Advisees class must contain a default constructor.
• Your Advisees class must provide a method with the following signature:

  public boolean inputStudents( Scanner inStream )
  {
  	// ...
  }


  The Advisees.inputStudents() method must correctly read all of the students data into Student objects, storing the new objects in a Vector or ArrayList.

• Your Advisees class must provide a method with the following signature:

  public boolean inputCourses( Scanner inStream )
  {
  	// ...
  }


  The Advisees.inputCourses() method must correctly read all of the students’ courses data into the course objects stored in the Student objects as a Vector or ArrayList.

• Your Advisees class must also provide a method with the following signature:

  public Student get( int index )
  {
  	// ...
  }


  The Advisees.get() method returns a reference to the Student at the corresponding index in the students Vector or ArrayList. Note: that the Vector or ArrayList must be in sorted order by name, (Last, First). (Only the student objects are to be sorted. The course objects must be maintained in the same order as they were input.) Note, if the list is null or the index is invalid then the method should return a null reference.

• Your Advisees class must also provide a method with the following signature:

  public Student find( String ID )
  {
  	// ...
  }


  The Advisees.find() method returns a reference to the Student with the corresponding ID number. Note: if the student Vector or ArrayList does not contain a Student object that matches the ID then a null reference must be returned.

• Your Advisees class must also provide a method with the following signature:

  public double mean( )
  {
  	// ...
  }


  The Advisees.mean() method simply returns the average of the student GPAs. Note that the returned double must rounded to the fourth decimal place. If the mean cannot be computed the method should return -1.0000.

• Your Advisees class must also provide a method with the following signature:

  public double stdDev( )
  {
  	// ...
  }


  The Advisees.stdDev() method returns the standard deviation of the student GPAs. Note that the returned double must rounded to the fourth decimal place. The computation of the standard deviation should use the value returned by the mean() method for the calculation. If the standard deviation cannot be computed the method should return -1.0000.

BarChart Interface

You must also provide an interface called BarChart.

public interface BarChart
{
    public void setMaxColLength( int maxColumns );
    public void setMaxRangeValue( double maxRange );
    public int getMaxColLength( );
    public double getMaxRangeValue( );

    public int getBarLength( double value );
}

BarChartGPAs Class

You must also provide a class called BarChartGPAs that implements the BarChart interface. Your BarChartGPAs class must also provide a default constructor.

Note that none of the methods in the BarChart interface throws any exceptions. In particular, this means that none of the methods provided by your BarChartGPAs class can throw I/O exceptions.

In addition, your BarChartGPAs class must have a default constructor that takes no parameters.

You are encouraged to design your solution piecemeal, (i.e., stepwise implementation). Begin by coding tests for the Student and Course classes. After you have coded the tests then implement the methods for the classes one at a time testing and debugging them separately. Think about using a possible driver/organizing class to instantiate and execute the Student and Course classes. Then identify the major tasks that have to remain be done, and then add detail for each of those tasks. Apply a similar strategy to the GPA computation process for this program. Then continue by coding tests for the Advisees and BarChartGPAs classes. Followed by implementing the Advisees and BarChartGPAs classes. Remember that by decomposing the problem you allow yourself to focus on solving a single part of the problem at any one time. You will find that this will greatly increase your odds of producing a correct solution.

When it comes to testing, remember to write one or more test cases for each method that your write in your solution. Preferably, you should write these tests before (or as) you write the method itself, rather than saving testing until your code works. As you work on larger and larger programs, it is important to build skills in convincing yourself that the parts you have already written work as you intend, even if the full solution has not been completed.

Also, in addition to trying to think of various cases that your methods should add formatting to, also write test cases for scenarios where a method should not take action (or should signal an error condition, if that is the behavior intended).

Finally, be sure to review the section on Testing I/O-based Operations in the Java stream I/O tutorial.

On BlueJ’s main menu, click Tools->Submit.... Click on "Browse...", double-click to open the "CS 1114 Programs" folder, and select CBE. Click "OK". Click "Submit". Click on the link provided in the submission response in order to view the results of the automated phase of program grading.

If no "CBE" entry is visible on BlueJ’s submission menu, then the Web-CAT Grader is not yet accepting submissions for this assignment. Wait for a message posted to this CBE web site that submissions are being accepted, and try again.

If any errors, warnings or suggestions are indicated, you can fix them and resubmit. You are expected to fix all such issues in your code. You may resubmit as many times as you like, up until the deadline. Be careful as the due time approaches--no late submissions will be accepted.
